DAMAR 23224B F22DTT/15MM/850 22W CFL Quad Tube 5000K GX32d-2 2-pin Base

Identification & Application

DAMAR 23224B F22DTT/15MM/850 22W CFL Quad Tube 5000K GX32d-2 2-pin Base

The DAMAR 23224B F22DTT/15MM/850 22W CFL Quad Tube 5000K GX32d-2 2-pin Base is a Damar compact fluorescent lamp with verified performance specifications including Wattage: 22W • Voltage: 120V Color temperature: 5000K • CRI: 82. It is intended for compatible recessed, task, wall, ceiling, commercial, institutional, hospitality, and residential luminaires designed for the exact plug-in cfl base and ballast configuration.

Construction and operation are defined by the exact manufacturer configuration for this SKU. Verified details include mounting or base configuration of GX32D-2; Lamp shape: Quad Tube • Base: GX32D-2 • Additional manufacturer information: TRUTONE QUAD COMPACT FLUORESCENT; product dimensions of Maximum overall length: 6.16 in. • Diameter: 1.72 in. • Length: 6.2 in.. Install only in equipment designed for the listed wattage, voltage, base, lamp shape, ballast or driver method, operating position, enclosure rating, mounting method, and control requirements.

For specification, purchasing, and maintenance planning, the manufacturer documentation confirms Rated life: 10000 hours; inner/package quantity: 10; case quantity: 50. All products should be installed and used in accordance with applicable electrical codes and the requirements of the compatible fixture or equipment.

Technical Performance Specifications
