DAMAR 36685A LED63CC/3CCT 45W/54W/63W LED HID Corn Retrofit Bulb 30K/40K/50K E26 Base 100-277V
Specifications & Downloads
DAMAR 36685A LED63CC/3CCT 45W/54W/63W LED HID Corn Retrofit Bulb 30...
Description
Description
Identification & Application
DAMAR 36685A LED63CC/3CCT 45W/54W/63W LED HID Corn Retrofit Bulb 30K/40K/50K E26 Base 100-277V
This Damar 36685A LED HID corn retrofit bulb is a field-selectable retrofit lamp designed for replacing existing HID lighting systems. The lamp operates on 100-277VAC 50/60Hz power systems and utilizes a standard E26 medium screw base for installation in compatible retrofit applications.
The lamp provides selectable wattage settings of 45W, 54W, or 63W and selectable color temperatures of 3000K, 4000K, or 5000K. Visible specifications confirm average initial lumen outputs of 6750, 8100, and 9450 lumens depending on the selected power setting.
The corn-style design delivers broad illumination for area lighting, post top fixtures, site lighting, and other HID retrofit applications. The lamp is not designed for use with dimmers or ballasts and is intended for direct line voltage operation.
Visible specifications confirm suitability for dry and damp locations with an IP54 rating, enclosed fixture compatibility, 4kV surge protection, and operation in ambient temperatures from -40°F to 113°F. The lamp provides an average rated life of 50,000 hours.
Technical Performance Specifications
