DAMAR 36688B LED120CC/3CCT 80W/100W/120W LED HID Corn Retrofit Bulb 30K/40K/50K EX39 Mogul Base 120-277V
Specifications & Downloads
DAMAR 36688B LED120CC/3CCT 80W/100W/120W LED HID Corn Retrofit Bulb...
Description
Description
Identification & Application
DAMAR 36688B LED120CC/3CCT 80W/100W/120W LED HID Corn Retrofit Bulb 30K/40K/50K EX39 Mogul Base 120-277V
This Damar 36688B LED HID corn retrofit bulb is a field-selectable retrofit lamp designed for replacing existing HID lighting systems. The lamp operates on 120-277VAC 50/60Hz power systems and utilizes an EX39 mogul base for installation in compatible retrofit fixtures.
The lamp provides selectable wattage settings of 80W, 100W, or 120W and selectable color temperatures of 3000K, 4000K, or 5000K. Visible specifications confirm average initial lumen outputs of 11200, 14000, and 16800 lumens depending on the selected power setting.
The corn-style design delivers omnidirectional illumination with a 360 degree beam spread, making it suitable for area lighting, site lighting, post top fixtures, and other HID retrofit applications requiring broad light distribution.
Visible specifications confirm Type B ballast bypass installation, optional sensor and remote dimming capability, enclosed fixture compatibility, 4kV surge protection, and operation in ambient temperatures from -40°F to 113°F. The lamp is suitable for dry and damp locations and provides an average rated life of 50,000 hours.
Technical Performance Specifications
