DAMAR 37361A LED14.5T8/850/4FT/BP/SS 14.5W 4ft LED T8 Tube 5000K Type B Ballast Bypass Safe-Shield Sleeve 120-277V

Identification & Application

DAMAR 37361A LED14.5T8/850/4FT/BP/SS 14.5W 4ft LED T8 Tube 5000K Type B Ballast Bypass Safe-Shield Sleeve 120-277V

The DAMAR 37361A LED14.5T8/850/4FT/BP/SS 14.5W 4ft LED T8 Tube 5000K Type B Ballast Bypass Safe-Shield Sleeve 120-277V is a premium LED T8 replacement lamp engineered for single-ended Type B ballast bypass installations. Operating directly from 120-277VAC line voltage, this high-efficiency 14.5W lamp delivers 2,200 initial lumens of crisp 5000K daylight illumination with an 82 CRI, making it an excellent solution for offices, schools, healthcare facilities, warehouses, manufacturing plants, retail spaces, and other commercial lighting applications.

Built with a durable Safe-Shield protective sleeve and a standard G13 medium bi-pin base, this LED tube requires single-ended direct-wire installation using the labeled end. Its 170° beam angle provides broad, uniform illumination while eliminating fluorescent ballast maintenance. Suitable for dry and damp locations, this lamp is not intended for use with dimmers or emergency lighting systems.

Designed for dependable long-term performance, the LED14.5T8/850/4FT/BP/SS is rated for 50,000 hours of service life. The integrated Safe-Shield sleeve helps contain glass in the event of breakage, making it ideal for facilities where safety and reduced maintenance are priorities. Installation should always follow the manufacturer's wiring instructions and applicable electrical codes.

Technical Performance Specifications
