Diode LED DI-ODX-24V288W-MT-J 288W Omnidrive X Multi-Tap Dimmable LED Driver Input 100-277 Output 24VDC

Identification & Application

Diode LED DI-ODX-24V288W-MT-J 288W OMNIDRIVE X Multi-Tap Dimmable LED Driver 100-277VAC Input 24VDC Output.

The Diode LED DI-ODX-24V288W-MT-J is a 24VDC constant voltage LED driver engineered to provide regulated low-voltage power for LED lighting systems requiring higher output capacity. The universal 100-277VAC input range supports installation across residential, commercial, retail, hospitality, and architectural lighting applications.

This OMNIDRIVE X Multi-Tap driver delivers up to 288 watts of output power and is designed to support multiple independent Class 2 load connections from a single driver. The multi-tap architecture simplifies installations requiring several separate LED tape light, linear lighting, cove lighting, shelving, display, or millwork lighting runs.

The driver supports ELV, TRIAC, and 0-10V dimming control systems and operates without a minimum load requirement. Its dimming compatibility makes it suitable for projects requiring smooth light level adjustment while maintaining stable low-voltage LED operation.

An integrated junction box and NEMA 3R enclosure allow installation in indoor and outdoor wet-location environments when properly installed according to applicable electrical codes. Internal protection circuitry provides automatic shutdown and recovery after fault conditions are cleared to help protect connected lighting systems.

Technical Performance Specifications
