LEDONE DR0097 LOC-EMDR-18W-AC-L 18W 2-Piece LED Emergency Driver 120-347V

Identification & Application

LEDone DR0097 LOC-EMDR-18W-AC-L 18W 2-Piece LED Emergency Driver 120-347V

The LEDone LOC-EMDR-18W-AC-L is a high-performance 2-piece LED emergency driver designed to provide dependable emergency illumination for compatible LED fixtures during power outages. Operating from a wide 100-347VAC input, the emergency driver automatically transfers connected luminaires into emergency mode, delivering constant 18-watt emergency output for up to 90 minutes to satisfy life safety lighting requirements. Its long battery pack configuration is ideal for fixtures with extended battery compartments while allowing both factory and field installation.

Engineered for reliable long-term performance, the LOC-EMDR-18W-AC-L features intelligent self-testing that automatically performs monthly 30-second diagnostic tests and annual 90-minute discharge tests in accordance with NFPA 101 Life Safety Code requirements. The integrated Li-ion/LiFePO4 battery includes over-temperature, over-charge, and over-discharge protection, while built-in malfunction indication and 3kV line-to-neutral surge protection simplify maintenance and enhance system reliability.

Designed for energy-efficient operation, the emergency driver delivers constant output power with low energy consumption and CEC compliance. UL924 listed and tested to CSA C22.2 No. 141 standards, the LOC-EMDR-18W-AC-L provides dependable emergency lighting performance backed by a 5-year limited warranty, making it an excellent choice for commercial offices, schools, healthcare facilities, warehouses, retail spaces, and other institutional applications.

Technical Performance Specifications
