LEDONE SL0080 LOC-4FTAWA5-MW(30/40/50)MCCT(35/40/50) 30/40/50W 4ft LED Arch Wrap Fixture 3500K/4000K/5000K 120-277V

Identification & Application

LEDone SL0080 LOC-4FTAWA5-MW(30/40/50)MCCT(35/40/50) 30/40/50W 4ft LED Arch Wrap Fixture 3500K/4000K/5000K 120-277V

The LEDone LOC-4FTAWA5-MW(30/40/50)MCCT(35/40/50) is a commercial-grade 4ft LED Arch Wrap Around Light with a built-in sensor base, engineered to deliver exceptional energy efficiency, uniform illumination, and dependable long-term performance. Featuring field-selectable 30W, 40W, and 50W power settings together with selectable 3500K, 4000K, and 5000K color temperatures, this versatile fixture allows installers to customize both light output and color temperature from a single luminaire. Producing up to 7,075 lumens with efficacy up to 141.5 lumens per watt, an 84 CRI, and a 120° beam angle, it provides bright, glare-free lighting for parking lots, supermarkets, corridors, retail spaces, warehouses, and other commercial applications.

Constructed with a durable SPCC steel housing finished in matte white and paired with a frosted polycarbonate lens, this LED arch wrap fixture is designed for years of reliable operation. Bridgelux 2835 LED chips provide excellent optical performance while standard 0-10V dimming enables smooth lighting control. Operating from a universal 120-277V input, the fixture supports both surface and suspension mounting. The integrated sensor base allows quick installation of optional PIR occupancy sensors, including Bluetooth-enabled models for advanced lighting control.

Designed for demanding commercial installations, the LOC-4FTAWA5-MW(30/40/50)MCCT(35/40/50) is IP20 rated for dry locations and delivers up to 50,000 hours of dependable service. Backed by a 5-year limited warranty, this energy-efficient LED wrap fixture helps reduce maintenance costs while providing consistent illumination. Optional emergency drivers, suspension kits, metal joiner brackets, occupancy sensors, and remote controls provide added installation flexibility for a wide range of commercial lighting projects.

Technical Performance Specifications
