LEDONE TP0020 LOC-PT-MW(25/50/75/100)MCCT(30/40/50) 25/50/75/100W LED Post-Top Area Light 3000K/4000K/5000K with Photocell 120-277V

Identification & Application

LEDone TP0020 LOC-PT-MW(25/50/75/100)MCCT(30/40/50) 25/50/75/100W LED Post-Top Area Light 3000K/4000K/5000K with Photocell 120-277V

The LEDone LOC-PT-MW(25/50/75/100)MCCT(30/40/50) is a commercial-grade LED Post-Top Area Light engineered to provide dependable architectural and area illumination with outstanding energy efficiency. Featuring selectable 25W, 50W, 75W, and 100W power settings together with selectable 3000K, 4000K, and 5000K color temperatures, this versatile luminaire allows installers to customize both light output and color appearance from a single fixture. Producing up to 11,686 lumens with efficacy up to 116.86 lumens per watt, it is ideal for parking decks, plazas, municipal lots, parks, shopping malls, housing complexes, and commercial outdoor lighting applications.

Constructed with a durable die-cast aluminum housing and equipped with premium Lumileds SMD2835 LED chips, the fixture delivers a wide 100° × 140° beam angle for uniform illumination. The IP65-rated housing, integrated surge protection, and built-in motion sensor with photocell provide dependable performance while automatically maximizing energy savings. Standard 0-10V dimming offers additional lighting control when required.

Designed for years of maintenance-free operation, the LOC-PT-MW(25/50/75/100)MCCT(30/40/50) mounts directly to standard 3-inch poles for quick installation. With a 50,000-hour rated life, a 5-year limited warranty, and DLC Premium certification, this LED post-top fixture is an excellent replacement for traditional 150W to 600W HID luminaires while significantly reducing maintenance and operating costs.

Technical Performance Specifications
