PLUSRITE 7247 BAMH1500-CWA/V4 1500W HID Magnetic Probe Start Metal Halide Ballast Kit 120/208/240/277V

Identification & Application

Plusrite 7247 BAMH1500-CWA/V4 1500W HID Magnetic Probe Start Metal Halide Ballast Kit 120/208/240/277V

The Plusrite 7247 BAMH1500-CWA/V4 is a 1500-watt magnetic probe start metal halide ballast kit designed to operate ANSI M48 metal halide lamps. Featuring four-tap 120/208/240/277V input capability, a CWA (Constant Wattage Autotransformer) circuit type, and a complete pre-wired component kit, this ballast delivers dependable starting and operating performance for commercial and industrial HID lighting systems.

This ballast kit is engineered for multi-voltage installations and includes the ballast, capacitor, mounting bracket, and wiring components required for standard probe start metal halide operation. Its Constant Wattage Autotransformer (CWA) design provides stable lamp performance, high power factor operation, and reliable compatibility with ANSI M48 metal halide systems. No ignitor is required for probe start lamps.

Operating from 120/208/240/277V input, the ballast consumes 1605 input watts with maximum line currents of 13.40A (120V), 7.75A (208V), 6.70A (240V), and 5.80A (277V). The ballast measures 4.33 × 6.33 inches, weighs 31.0 lbs, utilizes coil temperature code G/E/E/E, requires a 32µF / 525V minimum capacitor, and uses wiring diagram M1-V4.

Technical Performance Specifications
